Telecom backup rechargeable 48v battery pack 100Ah with high cycle times
See more pictures
Description:

FEATURES

Lithium Iron Phosphate (LiFePO4):the Safest Lithium Technology.

Integrated Battery Management System(BMS)



PERFORMANCE

Long Cycle Life >[email protected]%DOD.

High Discharge Current,High Temperature Range.

Free Maintenance.

Fast Charging.

Environment Friendly.

Fill out our short form and we will be contacting you shortly to see we how can provide a solution to your needs!

    Product Detail
    Feedback Now

    Telecom backup rechargeable 48v battery pack 100Ah with high cycle times

    Rechargeable battery

    Electrical Parameters
    Nominal Voltage51.2V
    Rated Capacity100Ah
    Energy4.8KWh
    Resistance≤2.5mΩ
    Efficiency0.99
    Cycle Life>4000cycles @1C,80% DOD
    Self Discharge2% per Month
    Max. Modules in Series/Parallel2P/16S



    Mechanical Parameters
    Dimension(L×W×H)400*442*190mm
    15.7*17.4*7.5"
    Weight48kg
    Terminal Type100A Plug type
    Battery HousingMetal
    Housing ProtectionIP54
    Cell Type-ChemistryLiFePO4 Cell
    SOC Display(Optional)/



    Discharge Parameters
    Continuous Discharge Current50A
    Maximum Discharge Current100A
    Recommended Volt. Disconnect40V
    BMS Discharge Cut-off Voltage35.2V
    Reconnect Voltage43.2V
    Short Circuit Protection300-800us



    Charge Parameters
    Charge MethodCC-CV
    Charge Voltage57.6~59.2V
    Recommended Float Voltage55V
    Recommended Charge Current50A
    Maximum Charge Current100A
    BMS Charge Cut-off Voltage60V



    Temperature Parameters
    Discharge Temperature-20 to 60 ℃
    Charge Temperature0 to 45 ℃
    Storage Temperature-20 to 45℃
    BMS High Temperature Cut-off78 ℃

    Q :Do you provide free sample ?
    A: Yes, a few pcs free sample can be provided, but freight will be charged

    Q: what is the warranty?
    A: one year

    Q:What is your payment term ?
    A: T/T,L/C

    Q:do you accepte OEM order ?
    A: Yes,you can print yourself logo, also we can provide the design of outlook for your special battery pack

    Q :How many cells you can produce per month?
    A: 1.8million

    Q :What is the mode of transport?
    A: usually by sea

    Q:Which certificates do you have
    A:We have un38.3,MSDS…etc.
